DHC Battery Testers

Specializing in Advanced Battery & Electrical Diagnostics

Accurate. Durable. Affordable.

START STOP
Impala
START STOP
START STOP

START-STOP Equipped Vehicles

Vehicles using START-STOP technology will automatically shut off the engine when the car is idling and then restart when the driver’s foot leaves the brake pedal. When the engine is powered off, the vehicle’s electrical system uses energy from the battery. The battery is used to restart the engine after each stopping event. It is reported that Start-stop vehicles provide up to 5 percent more fuel-efficiency and reduce CO2 emissions from vehicles. With the surge of START-STOP equipped vehicles entering the market, DHC has produced two advanced diagnostic battery testers to ensure every technician has the right tool for the job. Most automotive shops miss out on the opportunity to capture additional battery sales due to lack of equipment because of investment costs and lack of time for technicians to properly check the customer’s battery. The BT2010 and BT2000 battery testers are the solution to all your battery testing challenges. Ask our team today on how you can increase battery sales while dramatically reducing your cost on equipment.


The BT1100 is equipped with our latest operating system and a colored LCD to maximize usability and flexibility. The screen is also able to display cranking voltage graphs for easier judgement.



Features:

​

  • Battery, Cranking, and Charging System Tester

  • 6V, 12V, and 12V Start-Stop Battery Test

  • 12V & 24V Cranking/Charging System Test

  • 6V/12V Internal Resistance Test

  • TFT-LCD Display with Intuitive Graphical User Interface

  • USB Type-C Wired Connection

  • Supports DHC Result Management Software

  • Update Firmware In-Field via PC Software

  • 2” Thermal Printer & Customizable Facility Information

  • Detachable/Replaceable 5.9’ Cable

  • Built-in Clamp and Cable Diagnostic Capability

  • Strong and Durable Heavy-Duty Case Design

  • Recall and Print Last 500 Test Results

  • 12-Month Warranty



Each BT1100 kit includes:


Printing Paper

AA Batteries

Hard Case


The BT2410 is a fast, accurate, and easy-to-use battery and electrical system tester. Based on the DHC Performance Platform, it offers better accuracy, user experience, and flexibility.



Features:

  • Battery, Cranking, and Charging System Tester

  • 6V, 12V, and 12V Start-Stop Battery Test

  • 12V & 24V Cranking/Charging System Test

  • 6V/12V Internal Resistance Test

  • TFT-LCD Display with Intuitive Graphical User Interface

  • USB Type-A wired Connection

  • Supports DHC Result Management Software

  • Update Firmware In-Field via PC Software

  • Flexible Integrated Battery Type: AA or 18650 Li-Ion

  • Built-in 2” Thermal Printer

  • Detachable/Replaceable 5.9’ Cable

  • Built-in Clamp and Cable Diagnostic Capability

  • Strong and Durable Heavy-Duty Case Design

  • Recall and Print Last 7 Days Test Results

  • 12-Month Warranty



Each BT2410 kit includes:


Printing Paper

AA Batteries

Hard Case


The BT2400 is the next generation of battery testers. Based on the DHC Performance Platform, it offers better accuracy, user experience, and flexibility.



Features:

  • Battery, Cranking, and Charging System Tester

  • 6V, 12V, and 12V Start-Stop Battery Test

  • 12V & 24V Cranking/Charging System Test

  • 6V/12V Internal Resistance Test

  • TFT-LCD Display with Intuitive Graphical User Interface

  • USB Type-A wired Connection

  • Supports DHC Result Management Software

  • Update Firmware In-Field via PC Software

  • Flexible Integrated Battery Type: AA or 18650 Li-Ion

  • Thermal Sensor for Battery Temp Detection & Compensation.

  • Built-in 2” Thermal Printer

  • Detachable/Replaceable 5.9’ Cable

  • Built-in Clamp and Cable Diagnostic Capability

  • Strong and Durable Heavy-Duty Case Design

  • Recall and Print Last 7 Days Test Results

  • Optional Amp Clamp and Voltage Probe

  • 12-Month Warranty

​

Optional Accessories Items:


AMP Clamp

Volt Probe


The BT2400 PRO combines decades of battery testing know-how into one dependable and flexible package for professionals and enables tests to be conducted with speed, convenience, and accuracy.



Features:

​

  • Battery, Cranking, and Charging System Tester

  • 6V, 12V, and 12V Start-Stop Battery Test

  • 12V & 24V Cranking/Charging System Test and IR Test

  • TFT-LCD Display with Intuitive Graphical User Interface

  • Wired & Wireless Connectivity via WiFi or USB Type-A Port

  • Upload test results automatically through Wi-Fi.

  • Store and manage data through our cloud interface.

  • Integrated 1D/2D Barcode Scanner

  • Flexible Integrated Battery Type: AA or 18650 Li-Ion
    batteries

  • Thermal Sensor for Battery Temperature Detection and
    Compensation.

  • Built-in 2” Thermal Printer & Customizable Facility
    Information

  • Detachable/Replaceable 5.9’ Cable

  • Built-in Clamp and Cable Diagnostic Capability

  • Strong and Durable Heavy-Duty Case Design

  • Test Code Decoder for Decoding and Saving Test Records

  • Recall and Print Last 7 Days Test Results

  • 12-Month Warranty

​

Optional Accessories Items:


AMP Clamp

Volt Probe
